Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input.
The Switch Flex Mini (USW Flex Mini) is a fully managed, Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input. The USW Flex Mini can be powered with either PoE (via Port 1) or its included USB-C power adapter*. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.
Features:
-
- (1) GbE, 802.3af PoE RJ45 input
- (4) GbE RJ45 ports
- Compact, slim housing
- Can be powered with a 5V, 1A USB-C adapter*
| Mechanical |
| Dimensions |
107.16 x 70.15 x 21.17 mm (4.22 x 2.76 x 0.83") |
| Weight |
150 g (5.29 oz) |
Interfaces
Networking
PoE In
Management |
(5) 10/100/1000 Mbps RJ45 Ports
802.3af/at PoE (Pins 1, 2+; 3, 6-)
Ethernet In-Band |
| Total Non-Blocking Throughput |
5 Gbps |
| Switching Capacity |
10 Gbps |
| Forwarding Rate |
7.44 Mpps |
| Power Method |
USB Type C, 5V
802.3af/at PoE (44 - 57VDC, 0.05 - 0.04A) |
| Power Supply |
5V, 1A Power Adapter* |
Voltage Range
USB Type C
802.3af/at PoE |
4.7 - 5.3VDC
44 - 57VDC |
| Max. Power Consumption |
2.5W |
LEDs
System
RJ45 Data Ports |
Status
Speed/Link/Activity |
| ESD/EMP Protection |
± 16kV Air, ± 12kV Contact |
| Shock and Vibration |
ETSI300-019-1.4 Standard |
| Operating Temperature |
-5 to 45° C (23 to 113° F) |
| Operating Humidity |
10 to 90% Noncondensing |
| Certifications |
CE, FCC, IC |
* Included only with the single-pack of the USW-Flex-Mini.
